SENSOPAD™ – novel, low cost, inductive position sensors

Our client asked:

Can a low-cost, accurate and rugged, non-contact position sensing technology be created for the demanding industrial and automotive markets?

The project story:

• Sagentia Innovation has a track record of developing novel robust sensors and delivering them into various markets

• The first-generation of Sagentia Innovation’s inductive sensor technology was developed in the mid-1990s; this was successfully deployed in toys and other consumer applications such as pen input devices

• In the 2000’s, electronics technology had advanced, enabling Sagentia Innovation to further develop and patent a second generation of inductive sensor technology, which was lower cost and had a much faster response

• A spin-out company (Sensopad Technologies Limited) was formed to exploit this second generation technology, which was called Sensopad™

• The exclusive automotive rights to the Sensopad™ technology were bought by TT Electronics (now owned by Kyocera-AVX), who market the product as their Autopad™ range and an example is shown on the right

• Several other licenses were agreed to exploit the technology in non-automotive markets

• Sensopad™ ASICs were developed, initially for automotive products, but subsequently used in several other markets

Results: deliverables and outcomes

• TT Electronics achieved £100M of orders for their Autopad™ sensors displacing Hall-effect sensors in cars

• The robust technology continues to meet clients’ needs in many other applications, for example it allows non-contact sensing of valve & piston position and it enables precise dosing systems

• Sagentia Innovation continues to lead the development of inductive position sensing systems, with the third generation (InTrack and MuTrack) enabling higher accuracy and through-metal sensing
